Absolute Maximum Ratings

Stresses beyond those listed under the Absolute Maximum Rating table may cause permanent damage to the device. These are

stress ratings only and functional operation of the device at these or any other condition beyond those indicated in the operational

sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device

reliability.

Parameter

Rating

Unit

Input Voltage VIN

-0.3 to 6.5

V

Output Voltage VOUT

-0.3 to VIN

V

Chip Enable Input VEN

-0.3 to VIN

V

Output Current IOUT

300

mA

Lead Temperature Range

260

°C

Operating Junction Temperature TJ(MAX)

150

°C

Storage Temperature TSTG

-55 to 150

°C

MSL

Level-3

Thermal Resistance

250

°C/W

ESD

HBM

8000

V

MM

300

Recommend Operating Ratings

The Recommended Operating Conditions table defines the conditions for actual device operation. Recommended operating

conditions are specified to ensure optimal performance to the datasheet specifications. DIOO does not recommend exceeding them

or designing to absolute maximum ratings.

Parameter

Rating

Unit

Operating Supply voltage

1.6～5.5

V

Operating Temperature Range

-40～125

°C

Thermal Resistance, RθJA

250

°C/W
