RL78/D1A

4. ELECTRICAL SPECIFICATIONS (L GRADE PRODUCT)

R01DS0463EJ0120 Rev. 1.20

Page 100 of 135

Mar 31, 2026

4.4 DC characteristics

4.4.1 Pin group 1

TA = -40 to +105

°C, 4.0 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V (1/2)

Parameter

Symbols

Conditions

Min.

Typ.

Max.

Unit

Output current, highNote 1

IOH1

Per pin

-5.0

IOH2

Per pin, P73 or P135 (SG port)

-13.0

IOHTOTAL

Total

(for duty factors

≤ 70%Note 2)

Group 1L

-40.0

Group 1R

-40.0

Group 1C (128-pin,

100-pin)

-30.0

for 128-pin, 100-pin

-110.0

for 80-pin, 64-pin, 48-pin

-60.0

Output current, low

IOL1

Per pin

8.5

IOL2

Per pin, P73 or P135 (SG ports)

13.0

IOLTOTAL

Total

(for duty factors

≤ 70%Note 3)

Group 1L

40.0

Group 1R

35.0

Group 1C (128-pin,

100-pin)

40.0

for 128-pin, 100-pin

115.0

for 80-pin, 64-pin, 48-pin

60.0

Notes 1.

When P60 or P61 is set to Nch open drain mode, it does not drive high level output.

These output current values are obtained under the condition that the duty factor is no greater than 70%.

The output current values when the duty factor is changed to a value greater than 70% can be calculated

from the following expression (when the duty factor is changed to n%).

• Total output current of pins (IOH × 0.7)/(n × 0.01)

<Example> Where n = 80% and IOH = -30.0 mA

Total output current of pins = (-30.0

× 0.7)/(80 × 0.01) ≈ -26.2 mA

However, the current that is allowed to flow into one pin does not vary depending on the duty factor. A

current higher than the absolute maximum rating must not flow into one pin.

These output current values are obtained under the condition that the duty factor is no greater than 70%.

The output current values when the duty factor is changed to a value greater than 70% can be calculated

from the following expression (when the duty factor is changed to n%).

• Total output current of pins (IOL × 0.7)/(n × 0.01)

<Example> Where n = 80% and IOL = 40.0 mA

Total output current of pins = (40.0

× 0.7)/(80 × 0.01) = 35.0 mA

However, the current that is allowed to flow into one pin does not vary depending on the duty factor. A

current higher than the absolute maximum rating must not flow into one pin.

Caution Different voltage between EVDD and VDD is allowed only when LCDM register is initial value.
