R5F10CMDCLFB datasheet(137/139 Pages) RENESAS

137 / 139 page

R01DS0463EJ0120 Rev. 1.20

(A−2)

Mar 31, 2026

Rev

Date

Description

Page

Summary

1.20

Mar 31, 2026

p.48

Modification of table in Definition of Product Groups

p.71

Modification of table 3.5.1 Basic operation

p.74

Modification of table in 3.5.3 Sound generator

p.75

Modification of Master mode and Slave mode tables in 3.5.4 Serial Interface: CSI

Operation

p.76

Modification of Figure 3-7. CSI mode serial transfer timing

p.76

Modification of Figure 3-8. CSI mode serial transfer timing

p.80

Modification of title number in 3.5.9 LCD Bus Interface characteristics (128-pin

products only)

p.85

Modification of table in 3.7.1 A/D converter characteristics

p.89

Modification of table in Definition of Pin Groups

p.90

Modification of table in Definition of Product Groups

p.106

Modification of table in 4.4.3 Pin group 3 (SMC pins)

p.113

Modification of table 4.5.1 Basic operation

p.115

Modification of table in 4.5.2 Stepper motor controller/driver

p.116

Modification of table in 4.5.3 Sound generator

p.117

Modification of the Master mode and Slave mode tables in 4.5.4 Serial interface: CSI

operation

p.118

Modification of Figure 4-7. CSI mode serial transfer timing

p.118

Modification of Figure 4-8. CSI mode serial transfer timing

p.122

Modification of title number in 4.5.9 LCD Bus Interface characteristics (128-pin

products only)

p.127

Modification of table in 4.7.1 A/D converter characteristics

p.129

Modification of table in 4.7.4 LVD characteristics

p.131

Modification of description in 5.1 48-pin products

p.132

Modification of description in 5.2 64-pin products

p.133

Modification of description in 5.3 80-pin products

p.134

Modification of description in 5.4 100-pin products

p.135

Modification of description in 5.5 128-pin products

All trademarks and registered trademarks are the property of their respective owners.

SuperFlash is a registered trademark of Silicon Storage Technology, Inc. in several countries including the United States

and Japan.

Caution: This product uses SuperFlash® technology licensed from Silicon Storage Technology, Inc.
