www.nicerf.com

SA316S

NiceRF Wireless Technology Co., Ltd.

Rev 1.8

- 2 -

sales@nicerf.com

Catalogue

1. Overview .........................................................................................................................................................................3

2. Features...........................................................................................................................................................................3

3. Applications.................................................................................................................................................................... 3

4. Typical application circuit.............................................................................................................................................. 3

5. Electrical Characteristics ................................................................................................................................................4

7.Voltage and Power Correspondence Chart (SA316F30).................................................................................................6

8.Product configuration description ................................................................................................................................... 6

9. Typical application circuit.............................................................................................................................................. 8

10.Pin definition ............................................................................................................................................................... 10

11.Mechanical size (unit：mm)....................................................................................................................................... 13

Appendix: Furnace temperature curve diagram ...............................................................................................................13

Note: Revision History

Revision

Date

Comment

V1.0

2021-7

First release

V1.1

2022-6

Add product configuration instructions

V1.2

2022-8

Modify pin definition

V1.3

2023-2

Modify application circuit

V1.4

2023-8

Modify pin definition

V1.5

2024-4

Add SA316F30-TX parameters

V1.6

2024-11 Update configuration instructions, add power comparison table

V1.7

2025-3

Add SA316F30- parameters

V1.8

2026-3

Update delay time
