The popular single axis + θ axis stages as well as UVW stages can be used. The use of the same axis for both handling

and positioning simplifies machine configuration.

XY stage

UVWR stage

XYθ stage

X (Y) stage

θXY stage

Xθ (Yθ) stage

UVW stage

θX (θY) stage

Communication programs to connect robots from various vendors and FH flowcharts required for robot applications

are provided free of charge. You can quickly set up robot vision applications.

Robot Setting Tool simplifies connecting robots

Simple set-up steps

You can download the verified

robot communication programs

from the following

URL:http://www.omron-cxone.com/fh

There is no need to create a

program for robot calibration.

Move the robot for calibration

from the FH Series.

You don’t need to create a robot

program for verification.

Set the coordinates of the robot

and check robot operations

from the FH Series.

Pick

Offset compensation

Place

Combination

Applications

Stage Data calculates for various stages

Obtain robot

program

and flowchart

Calibrate

Check

operations
