11.Reliability

Content of Reliability Test (Wide temperature, -20℃~70℃)

Note1: No dew condensation to be observed.

Note2: The function test shall be conducted after 4 hours storage at the normal

Temperature and humidity after remove from the test chamber.

Note3: The packing have to including into the vibration testing.

Environmental Test

Test Item

Content of Test

Test Condition

Note

High Temperature

storage

Endurance test applying the high storage

temperature for a long time.

70℃

200hrs

2

Low Temperature

storage

Endurance test applying the low storage

temperature for a long time.

-30℃

200hrs

1,2

High Temperature

Operation

Endurance test applying the electric stress

(Voltage & Current) and the thermal stress to

the element for a long time.

70℃

200hrs

——

Low Temperature

Operation

Endurance test applying the electric stress

under low temperature for a long time.

-20℃

200hrs

1

High Temperature/

Humidity Operation

The module should be allowed to stand at 60

℃,90%RH max

60℃,90%RH

96hrs

1,2

Thermal shock

resistance

The sample should be allowed stand the

following 10 cycles of operation

-20℃

25℃

70℃

30min

5min

30min

1 cycle

-20℃/70℃

10 cycles

——

Vibration test

Endurance test applying the vibration during

transportation and using.

Total fixed

amplitude : 1.5mm

Vibration

Frequency :

10~55Hz

One cycle 60

seconds to 3

directions of X,Y,Z

for Each 15 minutes

3

Static electricity test Endurance test applying the electric stress to

the terminal.

VS=±600V(contact)

,

±800v(air),

RS=330Ω

CS=150pF

10 times

——
