5.Contour Drawing
The non-specified tolerance of dimension is ¡ Ó
0.3 mm .
326.5¡ Ó
0.5
163.25
39.4
44.5
57.07
44.5
57.07
44.5
307.4(OPENING AREA)
9.55
2-5.5
9.1¡ Ó
0.5
2-5.5
9.0¡ Ó
0.5
4-M3 USER HOLES
MAX. SCREW LENGTH 3.0mm.
DATA COF POSITION
(SYSTEM INTEGRATION MECHANICAL STRUCTURE
SHOULD NOT TOUCH THE POSITIONS OF DATA COF)
11.19
304.1(ACTIVE AREA)
Page 8 of 21
