background image
THERMAL DATA
Rthj-amb
Thermal Resistance Junction-ambient
Max
120
oC/W
ELECTRICAL CHARACTERISTICS (Tcase = 25
oC unless otherwise specified)
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
ICEV
Collector Cut-off
Current (VBE = -1.5V)
VCE = 700 V
VCE = 700 V
Tj = 125
o
1
5
mA
mA
IEBO
Emitter Cut-off
Current (IC = 0)
VEB = 9 V
1
mA
VCEO(sus)
∗ Collector-Emitter
Sustaining Voltage
(IB = 0)
IC = 1 mA
L = 25mH
400
V
VCE(sat)
∗ Collector-Emitter
Saturation Voltage
IC = 0.25 A
IB = 0.05 A
IC = 0.5 A
IB = 0.125 A
IC = 0.75 A
IB = 0.25 A
0.2
0.3
0.4
0.5
1
1.5
V
V
V
VBE(sat)
∗ Base-Emitter
Saturation Voltage
IC = 0.25 A
IB = 0.05 A
IC = 0.5 A
IB = 0.125 A
1
1.2
V
V
hFE
∗
DC Current Gain
IC = 0.4 A
VCE = 5 V
IC = 0.8 A
VCE = 5 V
10
5
30
20
tf
INDUCTIVE LOAD
Fall Time
IC = 0.25 A
Vclamp = 300 V
IB1 = -IB2 = 50 mA
L = 3 mH
0.3
µs
∗ Pulsed: Pulse duration = 300µs, duty cycle = 1.5 %
Safe Operating Area
Derating Curve
STBV42
2/5
