30 / 117 page  30 Draft.A - March 30, 2001 Preview - Confidential T89C51AC2 8. Data Memory 8.1. Introduction The T89C51AC2 provides data memory access in two different spaces: 1. The internal space mapped in three separate segments: • the lower 128 bytes RAM segment. • the upper 128 bytes RAM segment. • the expanded 1024 bytes RAM segment (ERAM). 2. The external space. A fourth internal segment is available but dedicated to Special Function Registers, SFRs, (addresses 80h to FFh) accessible by direct addressing mode. Figure 17 shows the internal and external data memory spaces organization. Figure 17. Internal and External Data Memory Organization 256 up to 1024 bytes Upper 128 bytes Internal RAM Lower 128 bytes Internal RAM Special Function Registers 80h 80h 00h FFh or 3FFh FFh 00h FFh 64 Kbytes External XRAM 0000h FFFFh direct addressing addressing 0100h up to 0400h 7Fh Internal ERAM direct or indirect indirect addressing EXTRAM= 0 EXTRAM= 1 |
|
