Remote control protocols
STFPC320
60/78
15.6.2
Matsushita in RAW format
In the raw form, the data is sent in the same way as it is received for each RC protocol
except that the header is not transmitted on SDA. If a valid SYN pulse is detected, it is
represented by a bit ‘1’. So a first bit with value ‘1’ implies that the data following it is a valid
raw format RC data. So for the above example for Matsushita protocol, the data on SDA pin
in raw-format will be as in Figure 39.
Figure 39.
Matsushita data structure in raw format
Data code
6-bit
Custom code
5-bit
LSB
MSB
LSB
MSB
LSB
LSB
MSB
MSB
Inverted Custom
code 5-bit
Inverted Data
code 6-bit
Sent first on SDA
