34 / 78 page ![]() Commands STFPC320 34/78 The first byte after the configuration command is in the following format: Figure 14. First byte format after configuration byte When b7 = ‘0’, incoming RC data is output on SDA in decoded format where the Device Address, Start Bit, Toggle Bit and Data Bits are sent. Note that the default location is 0x00 for the first device address. This order of the bits sent is in the same format as the incoming RC data. When b7 = ‘1’, incoming raw data (no header information) is output on SDA.Address decoding is still performed to decode the corresponding RC protocol. The format of the data on SDA corresponds to the format of the respective RC frame. For details, refer to the RC protocol section of the datasheet. Upon power application, the following modes are selected: ● Normal display setting: 16-digit, 12-segment mode is selected (default: display off and keyscan on). ● Remote control protocol setting: RC-5 with raw format. ● Guard timer setting: turned on with 10s. After the first command is processed by STFPC320, the guard timer is turned off until it is turned on by the host. ● Guard timer action: issue standby. b0 b1 b2 b3 b4 b5 b6 b7 MSB LSB GUARD TIMER SETTING 0000 : Turned off 0001 : 1 seconds 1111 : 15 seconds xxxx : No. of seconds in BCD format REMOTE CONTROL PROTOCOL SETTING (Decoded format since b7=‘0’) 0000 : RC Disable 0010 : RC-5 0011 : Reserved 0100 : NEC 0110 : R2000 0111 : RCA 0101 : Sony 0001: Matsushita b0 b1 b2 b3 b4 b5 b6 b7 MSB LSB GUARD TIMER SETTING 0000 : Turned off 0001 : 1 seconds 1111 : 15 seconds xxxx : No. of seconds in BCD format REMOTE CONTROL PROTOCOL SETTING (Decoded format since b7=‘0’) 0000 : RC Disable 0010 : RC-5 0011 : Reserved 0100 : NEC b0 b1 b2 b3 b4 b5 b6 b7 MSB LSB GUARD TIMER SETTING 0000 : Turned off 0001 : 1 seconds 1111 : 15 seconds xxxx : No. of seconds in BCD format REMOTE CONTROL PROTOCOL SETTING (Decoded format since b7=‘0’) 0000 : RC Disable 0010 : RC-5 0011 : Reserved 0100 : NEC 0110 : R2000 0111 : RCA 0101 : Sony 0001: Matsushita |
|
