Typical application

TS2012FC

6/31

Table 3.

External component descriptions

Components

Functional description

Supply capacitor that provides power supply filtering.

Input coupling capacitors (optional) that block the DC voltage at the amplifier input

Table 4.

Pin descriptions

Pin number

Pin name

Pin description

A1

Lin+

Left channel positive differential input

A2

PVCC

Power supply voltage

A3

Lout+

Left channel positive output

A4

Lout-

Left channel negative output

B1

Lin-

Left channel negative differential input

B2

G1

Gain select pin (MSB)

B3

STBYR

Standby pin (active low) for right channel output

B4

STBYL

Standby pin (active low) for left channel output

C1

Rin-

Right channel negative differential input

C2

G0

Gain select pin (LSB)

C3

AGND

Analog ground

C4

PGND

Power ground

D1

Rin+

Right channel positive differential input

D2

AVCC

Analog supply voltage

D3

Rout+

Right channel positive output

D4

Rout-

Right channel negative output
