STPC CLIENT

Issue 1.7 - February 8, 2000

3/48

•

ISA master/slave

•

The ISA clock generated from either

14.318MHz oscillator clock or PCI clock

•

Supports programmable extra wait state for

ISA cycles

•

Supports I/O recovery time for back to back I/

O cycles.

•

Fast Gate A20 and Fast reset.

•

Supports the single ROM that C, D, or E.

blocks shares with F block BIOS ROM.

•

Supports flash ROM.

•

Buffered DMA & ISA master cycles to reduce

bandwidth utilization of the PCI and Host bus.

•

IDE Interface

•

Supports PIO

•

Supports up to Mode 5 Timings

•

Supports up to 4 IDE devices

•

Individual drive timing for all four IDE devices

•

Concurrent channel operation (PIO modes) -

4 x 32-Bit Buffer FIFO per channel

•

Support for PIO mode 3 & 4

•

Support for 11.1/16.6 MB/s, I/O Channel

Ready PIO data transfers.

•

Supports both legacy & native IDE modes

•

Supports hard drives larger than 528MB

•

Support for CD-ROM and tape peripherals

•

Backward compatibility with IDE (ATA-1).

•

Integrated peripheral controller

•

2X8237/AT compatible 7-channel DMA con-

troller.

•

2X8259/AT compatible interrupt Controller.

16 interrupt inputs - ISA and PCI.

•

Three 8254 compatible Timer/Counters.

•

Power Management

•

Four power saving modes: On, Doze, Stand-

by, Suspend.

•

Programmable system activity detector

•

Supports SMM.

•

Supports STOPCLK.

•

Supports IO trap & restart.

•

Independent peripheral time-out timer to

monitor hard disk, serial & parallel ports.

•

Supports RTC, interrupts and DMAs wake-up
