Section 9 I/O Ports

Rev.1.00 Jun. 07, 2006 Page 491 of 1102

REJ09B0294-0100

9.3.7

Port Function Control Register 9 (PFCR9)

PFCR9 selects the multiple functions for the TPU I/O pins.

Bit

Bit Name

Initial Value

R/W

TPUMS5

R/W

TPUMS4

R/W

TPUMS3A

R/W

TPUMS3B

R/W

TPUMS2

R/W

TPUMS1

R/W

TPUMS0A

R/W

TPUMS0B

R/W

Bit

Bit Name

Initial

Value

R/W

Description

TPUMS5

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA5 function

0: Specifies pin P26 as output compare output and input

capture

1: Specifies P27 as input capture input and P26 as

output compare

TPUMS4

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA4 function

0: Specifies P25 as output compare output and input

capture

1: Specifies P24 as input capture input and P25 as

output compare

TPUMS3A 0

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA3 function

0: Specifies P21 as output compare output and input

capture

1: Specifies P20 as input capture input and P21 as

output compare

TPUMS3B 0

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCC3 function

0: Specifies P22 as output compare output and input

capture

1: Specifies P23 as input capture input and P22 as

output compare
