Section 9 I/O Ports
Rev.1.00 Jun. 07, 2006 Page 492 of 1102
REJ09B0294-0100
Bit
Bit Name
Initial
Value
R/W
Description
3
TPUMS2
0
R/W
TPU I/O Pin Multiplex Function Select
Selects TIOCA2 function
0: Specifies P36 as output compare output and input
capture
1: Specifies P37 as input capture input and P36 as
output compare
2
TPUMS1
0
R/W
TPU I/O Pin Multiplex Function Select
Selects TIOCA1 function
0: Specifies P34 as output compare output and input
capture
1: Specifies P35 as input capture input and P34 as
output compare
1
TPUMS0A 0
R/W
TPU I/O Pin Multiplex Function Select
Selects TIOCA0 function
0: Specifies P30 as output compare output and input
capture
1: Specifies P31 as input capture input and P30 as
output compare
0
TPUMS0B 0
R/W
TPU I/O Pin Multiplex Function Select
Selects TIOCC0 function
0: Specifies P32 as output compare output and input
capture
1: Specifies P33 as input capture input and P32 as
output compare
