Section 10 16-Bit Timer Pulse Unit (TPU)

Rev.1.00 Jun. 07, 2006 Page 506 of 1102

REJ09B0294-0100

Table 10.5

Input Clock Edge Selection

Clock Edge Selection

Input Clock

CKEG1

CKEG0

Internal Clock

External Clock

Counted at falling edge

Counted at rising edge

Counted at falling edge

Counted at both edges

[Legend]

X: Don't care

Table 10.6

TPSC2 to TPSC0 (Channel 0)

Channel

Bit 2

TPSC2

Bit 1

TPSC1

Bit 0

TPSC0

Description

Internal clock: counts on P

φ/1

Internal clock: counts on P

φ/4

Internal clock: counts on P

φ/16

Internal clock: counts on P

φ/64

External clock: counts on TCLKA pin input

External clock: counts on TCLKB pin input

External clock: counts on TCLKC pin input

External clock: counts on TCLKD pin input

Table 10.7

TPSC2 to TPSC0 (Channel 1)

Channel

Bit 2

TPSC2

Bit 1

TPSC1

Bit 0

TPSC0

Description

Internal clock: counts on P

φ/1

Internal clock: counts on P

φ/4

Internal clock: counts on P

φ/16

Internal clock: counts on P

φ/64

External clock: counts on TCLKA pin input

External clock: counts on TCLKB pin input

Internal clock: counts on P

φ/256

Counts on TCNT2 overflow/underflow

Note:

This setting is ignored when channel 1 is in phase counting mode.
