Section 15 Serial Communication Interface (SCI, IrDA, CRC)

Rev.1.00 Jun. 07, 2006 Page 669 of 1102

REJ09B0294-0100

Bit

Bit Name

Initial

Value

R/W

Description

CKE1

CKE0

R/W

Clock Enable 1, 0 (for SCI_2)

These bits select the clock source and SCK pin function.

• Asynchronous mode

00: On-chip baud rate generator

The SCK pin functions as I/O port.

01: On-chip baud rate generator

The clock with the same frequency as the bit rate is

output from the SCK pin.

1X: External clock or average transfer rate generator

When an external clock is used, the clock with a

frequency 16 times the bit rate should be input from

the SCK pin.

When an average transfer rate generator is used.

• Clocked synchronous mode

0X: Internal clock

The SCK pin functions as the clock output pin.

1X: External clock

The SCK pin functions as the clock input pin.

CKE1

CKE0

R/W

Clock Enable 1, 0 (for SCI_5 and SCI_6)

These bits select the clock source.

• Asynchronous mode

00: On-chip baud rate generator

1X: TMR clock input or average transfer rate generator

When an average transfer rate generator is used.

When TMR clock input is used.

• Clocked synchronous mode

Not available

[Legend]

Don't care
