Section 16 USB Function Module (USB)
Rev.1.00 Jun. 07, 2006 Page 779 of 1102
REJ09B0294-0100
• EPIR01
Bit
Bit Name
Initial
Value
R/W
Description
7, 6
D7, D6
Undefined
W
Endpoint Alternate Number
[Possible setting range]
0 or 1
5, 4
D5, D4
Undefined
W
Endpoint Transmission
[Possible setting range]
0: Control
1: Setting prohibited
2: Bulk
3: Interrupt
3
D3
Undefined
W
Endpoint Transmission Direction
[Possible setting range]
0: Out
1: In
2 to 0
D2 to D0
Undefined
W
Reserved
[Possible setting range]
Fixed to 0.
• EPIR02
Bit
Bit Name
Initial
Value
R/W
Description
7 to 1
D7 to D1
Undefined
W
Endpoint Maximum Packet Size
[Possible setting range]
0 to 64
0
D0
Undefined
W
Reserved
[Possible setting range]
Fixed to 0.
• EPIR03
Bit
Bit Name
Initial
Value
R/W
Description
7 to 0
D7 to D0
Undefined
W
Reserved
[Possible setting range]
Fixed to 0.
