Section 16 USB Function Module (USB)
Rev.1.00 Jun. 07, 2006 Page 783 of 1102
REJ09B0294-0100
Table 16.4
Relationship between TRNTREG0 Setting and Pin Output
Pin Input
Register Setting
Pin Output
VBUS
PTSTE
txenl
txse0
txdata
USD+
USD-
0
X
X
X
X
Hi-Z
Hi-Z
1
0
X
X
X
1
1
0
0
0
0
1
1
1
0
0
1
1
0
1
1
0
1
x
0
0
1
1
1
X
X
Hi-Z
Hi-Z
[Legend]
X:
Don't care.
:
Cannot be controlled. Indicates state in normal operation according to the USB operation
and port settings.
