867 / 1158 page  Section 16 USB Function Module (USB) Rev.1.00 Jun. 07, 2006 Page 815 of 1102 REJ09B0294-0100 16.10.7 Restrictions on Peripheral Module Clock (P φ) Operating Frequency Specify the peripheral module clock (P φ) for the USB at 14 MHz or more. To set the USB dedicated clock (cku) at 48 MHz, specify the peripheral module clock (P φ) as shown in table 16.8. Operation cannot be guaranteed if any frequency other than in the following table is specified. Table 16.8 Selection of Peripheral Clock (P φ) when USB is Connected MD_CLK EXTAL Input Clock Frequency USB Dedicated Clock (cku: 48 MHz) P φ 0 12 MHz EXTAL × 4 EXTAL × 2 (24 MHz) EXTAL × 1 (16 MHz) 1 16 MHz EXTAL × 3 EXTAL × 2 (32 MHz) |
|
