Section 1 Overview
Rev. 2.00 Sep. 24, 2008 Page 26 of 1468
REJ09B0412-0200
Classification
Pin Name
I/O
Description
NMI
Input
Non-maskable interrupt request signal. When this pin is not
in use, this signal must be fixed high.
Interrupt
IRQ11-A/IRQ11-B
IRQ10-A/IRQ10-B
IRQ9-A/IRQ9-B
IRQ8-A/IRQ8-B
IRQ7-A/IRQ7-B
IRQ6-A/IRQ6-B
IRQ5-A/IRQ5-B
IRQ4-A/IRQ4-B
IRQ3-A/IRQ3-B
IRQ2-A/IRQ2-B
IRQ1-A/IRQ1-B
IRQ0-A/IRQ0-B
Input
Maskable interrupt request signal.
DREQ0-A/DREQ0-B
DREQ1-A/DREQ1-B
DREQ2
DREQ3
Input
Requests DMAC activation.
DACK0-A/DACK0-B
DACK1-A/DACK1-B
DACK2
DACK3
Output
DMAC single address-transfer acknowledge signal.
DMA controller
(DMAC)
TEND0-A/TEND0-B
TEND1-A/TEND1-B
TEND2
TEND3
Output
Indicates end of data transfer by the DMAC.
