Section 25 Flash Memory
Rev. 2.00 Sep. 24, 2008 Page 1170 of 1468
REJ09B0412-0200
25.10
Flash Memory Emulation Using RAM
For realtime emulation of the data written to the flash memory using the on-chip RAM, the on-
chip RAM area can be overlaid with several flash memory blocks (user MAT) using the RAM
emulation register (RAMER).
The overlaid area can be accessed from both the user MAT area specified by RAMER and the
overlaid RAM area. The emulation can be performed in user mode and user program mode.
Figure 25.19 shows an example of emulating realtime programming of the user MAT.
Emulation program start
Set RAMER
Write tuning data to overlaid
RAM area
Execute application program
Tuning OK?
Cancel setting in RAMER
Program emulation block
in user MAT
Emulation program end
Yes
No
Figure 25.19 RAM Emulation Flow
