background image
Section 9 Bus Controller (BSC)
Rev. 2.00 Sep. 24, 2008 Page 225 of 1468
REJ09B0412-0200
9.5
External Bus
9.5.1
Input/Output Pins
Table 9.2 shows the pin configuration of the bus controller and table 9.3 shows the pin functions
on each interface.
Table 9.2
Pin Configuration
Name
Symbol
I/O
Function
Bus cycle start
BS
Output
Signal indicating that the bus cycle has started
Address strobe/
address hold
AS/AH
Output
Strobe signal indicating that the basic bus, byte control
SRAM, or burst ROM space is accessed and address
output on address bus is enabled
Signal to hold the address during access to the
address/data multiplexed I/O interface
Read strobe
RD
Output
Strobe signal indicating that the basic bus, byte control
SRAM, burst ROM, or address/data multiplexed I/O space
is being read
Read/write
RD/
WR
Output
Signal indicating the input or output direction
Write enable signal of the SRAM during access to the
byte control SRAM space
Low-high write/
lower-upper byte
select
LHWR/LUB
Output
Strobe signal indicating that the basic bus, burst ROM,
or address/data multiplexed I/O space is written to,
and the upper byte (D15 to D8) of data bus is enabled
Strobe signal indicating that the byte control SRAM
space is accessed, and the upper byte (D15 to D8) of
data bus is enabled
Low-low write/
lower-lower byte
select
LLWR/LLB
Output
Strobe signal indicating that the basic bus, burst ROM,
or address/data multiplexed I/O space is written to,
and the lower byte (D7 to D0) of data bus is enabled
Strobe signal indicating that the byte control SRAM
space is accessed, and the lower byte (D7 to D0) of
data bus is enabled
