Section 10 DMA Controller (DMAC)

Rev. 2.00 Sep. 24, 2008 Page 378 of 1468

REJ09B0412-0200

10.2

Input/Output Pins

Table 10.1 shows the pin configuration of the DMAC.

Table 10.1

Pin Configuration

Channel

Pin Name

Abbr.

I/O

Function

DMA transfer request 0

DREQ0

Input

Channel 0 external request

DMA transfer acknowledge 0

DACK0

Output

Channel 0 single address transfer

acknowledge

DMA transfer end 0

TEND0

Output

Channel 0 transfer end

DMA transfer request 1

DREQ1

Input

Channel 1 external request

DMA transfer acknowledge 1

DACK1

Output

Channel 1 single address transfer

acknowledge

DMA transfer end 1

TEND1

Output

Channel 1 transfer end

DMA transfer request 2

DREQ2

Input

Channel 2 external request

DMA transfer acknowledge 2

DACK2

Output

Channel 2 single address transfer

acknowledge

DMA transfer end 2

TEND2

Output

Channel 2 transfer end

DMA transfer request 3

DREQ3

Input

Channel 3 external request

DMA transfer acknowledge 3

DACK3

Output

Channel 3 single address transfer

acknowledge

DMA transfer end 3

TEND3

Output

Channel 3 transfer end
