Section 2 CPU

Rev. 2.00 Sep. 24, 2008 Page 50 of 1468

REJ09B0412-0200

2.7

Instruction Set

The H8SX CPU has 87 types of instructions. The instructions are classified by function as shown

in table 2.1. The arithmetic operation, logic operation, shift, and bit manipulation instructions are

called operation instruction in this manual.

Table 2.1

Instruction Classification

Function

Instructions

Size

Types

MOV

B/W/L

MOVFPE, MOVTPE

POP, PUSH*

W/L

LDM, STM

Data transfer

MOVA

B/W*

EEPMOV

MOVMD

B/W/L

Block transfer

MOVSD

ADD, ADDX, SUB, SUBX, CMP, NEG, INC, DEC

B/W/L

DAA, DAS

ADDS, SUBS

MULXU, DIVXU, MULXS, DIVXS

B/W

MULU, DIVU, MULS, DIVS

W/L

MULU/U*

6, MULS/U*6

EXTU, EXTS

W/L

TAS

MAC*

—

LDMAC*

6, STMAC*6

—

Arithmetic

operations

CLRMAC*

—

Logic operations

AND, OR, XOR, NOT

B/W/L

Shift

SHLL, SHLR, SHAL, SHAR, ROTL, ROTR, ROTXL, ROTXR

B/W/L

BSET, BCLR, BNOT, BTST, BAND, BIAND, BOR, BIOR,

BXOR, BIXOR, BLD, BILD, BST, BIST

BSET/EQ, BSET/NE, BCLR/EQ, BCLR/NE, BSTZ, BISTZ

Bit manipulation

BFLD, BFST
