Section 10 DMA Controller (DMAC)
Rev. 2.00 Sep. 24, 2008 Page 428 of 1468
REJ09B0412-0200
Figure 10.22 shows a transfer example when multiple transfer requests from channels 0 to 2.
Channel 0
Channel 1
Bus
released
Bus
released
Channel 2
Channel 0 transfer
Channel 1 transfer
Channel 2 transfer
Channel 0
Channel 1
Channel 2
Wait
Wait
Request cleared
Request cleared
Request cleared
Request
retained
Request
retained
Request
retained
Selected
Selected
Not
selected
Address bus
Channel 0
Channel 1
Channel 2
B
φ
DMAC
operation
Figure 10.22 Example of Timing for Channel Priority
