Section 13 I/O Ports

Rev. 2.00 Sep. 24, 2008 Page 609 of 1468

REJ09B0412-0200

13.2

Output Buffer Control

This section describes the output priority of each pin.

The name of each peripheral module pin is followed by "_OE". This (for example: TIOCA4_OE)

indicates whether the output of the corresponding function is valid (1) or if another setting is

specified (0). Table 13.5 lists each port output signal's valid setting. For details on the

corresponding output signals, see the register description of each peripheral module. If the name

of each peripheral module pin is followed by A or B, the pin function can be modified by the port

function control register (PFCR). For details, see section 13.3, Port Function Controller.

For a pin whose initial value changes according to the activation mode, "initial value E" indicates

the initial value when the LSI is started up in external extended mode and "initial value S"

indicates the initial value when the LSI is started in single-chip mode.

13.2.1

Port 1

(1)

P17/

IRQ7-A/TCLKD-B/SCL0/EDRAK1 /ADTRG1

The pin function is switched as shown below according to the combination of the EXDMAC and

IIC2 register settings and P17DDR bit setting.

Setting

EXDMAC

IIC2

I/O Port

Module Name

Pin Function

EDRAK1_OE

SCL0_OE

P17DDR

EXDMAC

EDRAK1 output



IIC2

SCL0 input/output



I/O port

P17 output

P17 input

(initial value)
