Section 13 I/O Ports

Rev. 2.00 Sep. 24, 2008 Page 676 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

Value

R/W

Description

TPUMS8

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA8 function.

0: Specifies PJ6 as output compare output and input

capture

1: Specifies PJ7 as input capture input and PJ6 as output

compare

TPUMS7

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA7 function.

0: Specifies PJ4 as output compare output and input

capture

1: Specifies PJ5 as input capture input and PJ4 as output

compare

TPUMS6A 0

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA6 function.

0: Specifies PJ0 as output compare output and input

capture

1: Specifies PJ1 as input capture input and PJ0 as output

compare

TPUMS6B 0

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCC6 function.

0: Specifies PJ2 as output compare output and input

capture

1: Specifies PJ3 as input capture input and PJ2 as output

compare
