Section 14 16-Bit Timer Pulse Unit (TPU)

Rev. 2.00 Sep. 24, 2008 Page 691 of 1468

REJ09B0412-0200

Unit

Channel

Symbol

I/O

Function

TCLKE

Input

External clock E input pin

(Channel 7 and 11 phase counting mode A phase input)

TCLKF

Input

External clock F input pin

(Channel 7 and 11 phase counting mode B phase input)

TCLKG

Input

External clock G input pin

(Channel 8 and 10 phase counting mode A phase input)

All

TCLKH

Input

External clock H input pin

(Channel 8 and 10 phase counting mode B phase input)

TIOCA6

I/O

TGRA_6 input capture input/output compare output/PWM output pin

TIOCB6

I/O

TGRB_6 input capture input/output compare output/PWM output pin

TIOCC6

I/O

TGRC_6 input capture input/output compare output/PWM output pin

TIOCD6

I/O

TGRD_6 input capture input/output compare output/PWM output pin

TIOCA7

I/O

TGRA_7 input capture input/output compare output/PWM output pin

TIOCB7

I/O

TGRB_7 input capture input/output compare output/PWM output pin

TIOCA8

I/O

TGRA_8 input capture input/output compare output/PWM output pin

TIOCB8

I/O

TGRB_8 input capture input/output compare output/PWM output pin

TIOCA9

I/O

TGRA_9 input capture input/output compare output/PWM output pin

TIOCB9

I/O

TGRB_9 input capture input/output compare output/PWM output pin

TIOCC9

I/O

TGRC_9 input capture input/output compare output/PWM output pin

TIOCD9

I/O

TGRD_9 input capture input/output compare output/PWM output pin

TIOCA10

I/O

TGRA_10 input capture input/output compare output/PWM output pin

TIOCB10

I/O

TGRB_10 input capture input/output compare output/PWM output pin

TIOCA11

I/O

TGRA_11 input capture input/output compare output/PWM output pin

TIOCB11

I/O

TGRB_11 input capture input/output compare output/PWM output pin
