Section 14 16-Bit Timer Pulse Unit (TPU)
Rev. 2.00 Sep. 24, 2008 Page 759 of 1468
REJ09B0412-0200
14.9
Operation Timing
14.9.1
Input/Output Timing
(1)
TCNT Count Timing
Figure 14.31 shows TCNT count timing in internal clock operation, and figure 14.32 shows TCNT
count timing in external clock operation.
P
φ
Internal clock
TCNT input
clock
TCNT
Falling edge
Rising edge
N
− 1N + 1N + 2
N
Falling edge
Figure 14.31 Count Timing in Internal Clock Operation
P
φ
External clock
TCNT input
clock
TCNT
Falling edge
Rising edge
N
− 1N + 1N + 2
N
Falling edge
Figure 14.32 Count Timing in External Clock Operation
