Section 17 32K Timer (TM32K)
Rev. 2.00 Sep. 24, 2008 Page 848 of 1468
REJ09B0412-0200
• TCNT32K3
Bit
Bit Name
Initial value
R/W
7
0
R
6
0
R
5
0
R
4
0
R
3
0
R
2
0
R
1
0
R
0
0
R
(2)
EXCKSN = 0 (Counter-Extended Mode)
The timer counter operates as a 24-bit counter. TCNT32K1, TCNT32K2, and TCNT32K3 are
employed for this purpose. Be sure to read from TCNT32K1 when reading the timer counter.
• TCNT32K1
Bit
Bit Name
Initial value
R/W
7
TCNT23
0
R
6
TCNT22
0
R
5
TCNT21
0
R
4
TCNT20
0
R
3
TCNT19
0
R
2
TCNT18
0
R
1
TCNT17
0
R
0
TCNT16
0
R
• TCNT32K2
Bit
Bit Name
Initial value
R/W
7
TCNT15
0
R
6
TCNT14
0
R
5
TCNT13
0
R
4
TCNT12
0
R
3
TCNT11
0
R
2
TCNT10
0
R
1
TCNT9
0
R
0
TCNT8
0
R
• TCNT32K3
Bit
Bit Name
Initial value
R/W
7
TCNT7
0
R
6
TCNT6
0
R
5
TCNT5
0
R
4
TCNT4
0
R
3
TCNT3
0
R
2
TCNT2
0
R
1
TCNT1
0
R
0
TCNT0
0
R
Note:
A correct value cannot be read if the counter is read while the subclock oscillator is not in
operation (OSC32STP
= 1).
