Section 20 USB Function Module (USB)
Rev. 2.00 Sep. 24, 2008 Page 999 of 1468
REJ09B0412-0200
Table 20.5
Relationship between Pin Input and TRNTREG1 Monitoring Value
Register Setting
Pin Input
TRNTREG1
Monitoring Value
PTSTE
SUSPEND
VBUS
USD+
USD-
xver_data dpls
dmns Remarks
0
X
X
X
X
0
0
0
Cannot be monitored
when PTSTE = 0
1
0
1
0
0
X
0
0
1
0
1
0
1
0
0
1
1
0
1
1
0
1
1
0
1
0
1
1
1
X
1
1
1
1
1
0
0
0
0
0
1
1
1
0
1
0
0
1
1
1
1
1
0
0
1
0
1
1
1
1
1
0
1
1
Can be monitored
when PTSTE = 1
1
X
0
X
X
0
1
1
Can be monitored
when VBUS = 0
[Legend]
X:
Don't care.
