1148 / 1504 page  Section 25 Flash Memory Rev. 2.00 Sep. 24, 2008 Page 1116 of 1468 REJ09B0412-0200 25.6 Input/Output Pins The flash memory is controlled through the input/output pins shown in table 25.2. Table 25.2 Pin Configuration Abbreviation I/O Function RES Input Reset EMLE Input On-chip emulator enable pin (EMLE = 0 for flash memory programming/erasure) MD3 to MD0 Input Set operating mode of this LSI PM2 Input SCI boot mode/USB boot mode setting (for boot mode setting by MD3 to MD0) TxD4 Output Serial transmit data output (used in SCI boot mode) RxD4 Input Serial receive data input (used in SCI boot mode) USD +, USD− I/O USB data I/O (used in USB boot mode) VBUS Input USB cable connection/disconnection detect (used in USB boot mode) PM3 Input USB bus power mode/self power mode setting (used in USB boot mode) PM4 Output D + pull-up control (used in USB boot mode) |
|
