Section 25 Flash Memory
Rev. 2.00 Sep. 24, 2008 Page 1144 of 1468
REJ09B0412-0200
(1)
Features
• Bus power mode and self power mode are selectable.
• The PM4 pin supports the D+ pull-up control connection.
• For enumeration information, refer to table 25.7.
Table 25.7
Enumeration Information
USB standard
Ver.2.0 (Full speed)
Transfer mode
Transfer mode Control (in, out), Bulk (in, out)
For self power mode (PM3 = 0)
100 mA
Maximum power consumption
For bus power mode (PM3 = 1)
500 mA
Endpoint configuration
EP0 Control (in out) 8 bytes
Configuration 1
InterfaceNumber0
AlternateSetting0
EP1 Bulk (out) 64 bytes
EP2 Bulk (in) 64 bytes



Html Pages
