Section 7 Interrupt Controller

Rev. 2.00 Sep. 24, 2008 Page 140 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

Value

R/W

Description

IRQ14SR*

IRQ14SF*

R/W

IRQ14 Sense Control Rise

IRQ14 Sense Control Fall

IRQ14 is used as the voltage monitoring interrupt in

LVD. Set falling edge interrupt request for use.

00: Initial value

01: Interrupt request generated at falling edge of

IRQ14

input

10: Setting is prohibited

11: Setting is prohibited

11 to 8



All 0

R/W

Reserved

These bits are always read as 0. The write value should

always be 0.

IRQ11SR

IRQ11SF

R/W

IRQ11 Sense Control Rise

IRQ11 Sense Control Fall

00: Interrupt request generated by low level of

IRQ11

01: Interrupt request generated at falling edge of

IRQ11

10: Interrupt request generated at rising edge of

IRQ11

11: Interrupt request generated at both falling and rising

edges of

IRQ11

IRQ10SR

IRQ10SF

R/W

IRQ10 Sense Control Rise

IRQ10 Sense Control Fall

00: Interrupt request generated by low level of

IRQ10

01: Interrupt request generated at falling edge of

IRQ10

10: Interrupt request generated at rising edge of

IRQ10

11: Interrupt request generated at both falling and rising

edges of

IRQ10
