Alarms and Warnings as TXFAULT Source

Alarms and warnings are not sources for TXFAULT with

the default setting. To set alarms as a TXFAULT source

set OEMCFG4 bit 6 to 1. To set warnings as a

TXFAULT, source set OEMCFG4 bit 7 to 1. The alarms

and warnings TXFAULT sources can be masked

individually in the same way shown in Tables 7 and 8.

Latching of Alarms and Warnings

Alarms and warnings are latched by default, i.e., once

asserted the flags remain ON until the register is read or

TXDSABLE is toggled. If OEMCFG4 bit 5 is set to 1, the

warnings are not latched and will be set and reset with

the warning condition. Reading the register or toggling

TXDISABLE will clear the flag. If OEMCFG4 bit 4 is set

to 1, the alarms are not latched and will be set and reset

with the alarm condition. Reading the register or toggling

TXDISABLE will clear the flag.

SMBus Multipart Support

If more than one MIC3003 device shares the same serial

interface and multipart mode is selected on them

(OEMCFG5 bit 3 = 1), then pin 7 and pin 20 become

SMBus address bits 3 and 4 respectively. Therefore, the

parts should have a different setting on those pins to

create four address combinations based upon the state

of pin 7 and pin 20 state, (00, 01, 10, 11) where 0 is a

pull down to GND and 1 is a pull up to VCC. The parts

come from the factory with the same address (A0) and

multipart mode off (OEMCFG5 bit 3 is 0). After power

up, write 1 to OEMCFG5 bit 3 to turn ON multipart mode,

which is done to all parts at the same time since they all

respond to serial address A0 at this point. With multipart

mode on, the parts have now different addresses based

on the states of pins 7 and 20. Another option is to

access each part individually, set their single mode

address in OEMCFG2 bits [4-7] to different values and

then turn off multipart mode to return to normal mode

where the parts have new different addresses.

QGOP Pin Function

QGOP can be used in GOP mode as a general purpose

output by setting OEMCFG3 bit 7 to 0, or as in RESET

mode as a reset signal output by setting OEMCFG3 bit 7

to 1.

If RESET mode is selected, the reset signal state is

controlled by RSETOUT (A2:FFh bits [2-0]). By default,

these three bits are 000, and the QGPO output is

undriven (state: High). When the three bits are written to

111, QGPO’s open-drain output will be driven low for

125 μs (typical), after which QGPO reenters the undriven

state. The RESETOUT field is cleared from 111 to 000

22.5 ms (typical) after the de-assertion edge of QGPO.

Other values of this delay may be selected by setting

TRSTCLR (OEMCFG2 bits [2-0]) to different values as

shown on table.

If Reset mode in OEMCFG3 is not selected, these three

bits have no function.

TRSTCLR

[2-0]

Delay from QGPO

Switching high to

RESETOUT clear

000

Zero delay

001

17.5 ms typical

010

22.5 ms typical (default)

011

27 ms typical

100

45 ms typical

Table 9. RESETOUT Clear Delay
