21
TPR0441BX–SMS–09/09
ATVaultIC460
Figure 3-11.
Pinout ATVaultIC460 - Package SOIC8 - SPI and I²C configurations
Figure 3-12.
Pinout ATVaultIC460 - Package SOIC8 - ISO configuration
ATVaultIC460
SOIC8 / SPI / I²C
INDEX CORNER
MOSI
GND
1
2
3
4
8
7
6
5
MISO
VCC
RST
SCK
SCL / SS
SDA / SPI_SEL
ATVaultIC460
SOIC8 / ISO7816
INDEX CORNER
GND
IO0
1
2
3
4
8
7
6
5
VCC
CLK
RST
