Chapter 19 S12X Debug (S12XDBGV2) Module

MC9S12XDP512 Data Sheet, Rev. 2.21

710

Freescale Semiconductor

Table 19-28 shows the effect for RWE and RW on the comparison conditions. These bits are not useful for

tagged operations since the trigger occurs based on the tagged opcode reaching the execution stage of the

instruction queue. Thus, these bits are ignored if tagged triggering is selected.

(COMP B/D)

Size Comparator Value Bit — The SZ bit selects either word or byte access size in comparison for the

associated comparator. This bit is ignored if the SZE bit is cleared or if the TAG bit in the same register is set.

This bit position has NDB functionality for comparators A and C

0 Word access size will be compared

1 Byte access size will be compared

TAG

Tag Select — This bit controls whether the comparator match will cause a trigger or tag the opcode at the

matched address. Tagged opcodes trigger only if they reach the execution stage of the instruction queue.

0 Trigger immediately on match

1 On match, tag the opcode. If the opcode is about to be executed a trigger is generated

BRK

Break — This bit controls whether a comparator match can cause an immediate breakpoint independent of state

sequencer state. The module breakpoints must be enabled using the DBGC1 bits DBGBRK[1:0].

0 Breakpoints may only be generated from this channel when the state machine reaches ﬁnal state.

1 A match on this channel generates an immediate breakpoint, tracing, if active, is terminated and the module

disarmed.

Read/Write Comparator Value Bit — The RW bit controls whether read or write is used in compare for the

associated comparator. The RW bit is not used if RWE = 0.

0 Write cycle will be matched

1 Read cycle will be matched

RWE

Read/Write Enable Bit — The RWE bit controls whether read or write comparison is enabled for the associated

comparator. This bit is not useful for tagged operations.

1 Read/Write is used in comparison

0 Read/Write is not used in comparison

SRC

SRC — Determines mapping of comparator to CPU or XGATE

0 The comparator is mapped to CPU busses

1 The comparator is mapped to XGATE address and data busses

COMPE

Comparator Enable Bit— Determines if comparator is enabled

0 The comparator is not enabled

1 The comparator is enabled for state sequence triggers or tag generation

Table 19-28. Read or Write Comparison Logic Table

RWE Bit

RW Bit

RW Signal

Comment

RW not used in comparison

Write data bus

No match

Read data bus

Table 19-27. DBGXCTL Field Descriptions (continued)

Field

Description
