Electrical characteristics
START499D
4/18
Doc ID 14496 Rev 4
2
Electrical characteristics
2.1
Static
2.2
Dynamic
Table 4.
Static TCASE = +25
oC
Symbol
Test conditions
Min.
Typ.
Max.
Unit
ICBO
VCB = 15 V
5
µA
IEBO
VEB = 1.2 V
250
µA
BVCES
IC = 200 µA15
20
V
hFE
VCE = 3 V
IC = 0.16 A
150
Table 5.
Dynamic
Symbol
Test conditions
Min.
Typ.
Max.
Unit
POUT
VCC = 3.6 V, ICQ = 30 mA, PIN = 15 dBm, f = 900 MHz
28
29
dBm
GP
13
14
dB
hD
55
65
%
Load
mismatch
VCC = 3.6 V, ICQ = 30 mA, POUT = 28 dBm, f = 900 MHz
All phase angles
3:1
VSWR
