PCF8564A
Real time clock and calendar
18. Packing information
18.1 Wafer and Film Frame Carrier (FFC) information
Wafer thickness, see Table 34.
Fig 30. Wafer layout of PCF8564AU
X
Saw lane
detail X
Marking code
Straight edge
of the wafer
013aaa037
Pin 1
18
μm
die type 1 = 84
μm
die type 2 = 74
μm
die type 1 = 84
μm
die type 2 = 74
μm
Seal ring plus gap to
active circuit ~18
μm
18
μm
