GS7025 PRO-LINX™ Serial Digital Receiver
Data Sheet
13813 - 7
October 2009
21 of 23
5. Package & Ordering Information
5.1 Package Dimensions
10.00 ±0.10
13.20 ±0.25
PIN 1
10.00
±0.10
0.80 BSC
0.45 MAX
0.30 MIN
13.20
±0.25
2.20 MAX
1.85 MIN
0.35 MAX
0.15 MIN
2.55 MAX
0.23
MAX.
1.60
REF
0.3 MAX.
RADIUS
0.13 MIN.
RADIUS
0.88
NOM.
0.20 MIN
5° to 16°
5° to 16°
7° MAX
0° MIN
0° MIN
44 pin MQFP
All dimensions in millimetres
