ADL5240

Rev. 0 | Page 8 of 24

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage (VDD, VCC)

6.5 V

Input Power

AMPIN

16 dBm

DSAIN

30 dBm

Internal Power Dissipation

0.5 W

θJA (Exposed Pad Soldered Down)

36.8°C/W

θJC (Exposed Pad is the Contact)

6.9°C/W

Maximum Junction Temperature

150°C

Lead Temperature (Soldering, 60 sec)

240°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

ESD CAUTION

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
