1 / 5 page

UNISONIC TECHNOLOGIES CO., LTD

UTL1426

Power MOSFET

www.unisonic.com.tw

1 of 5

QW-R502-264.A

N-CHANNEL ENHANCEMENT

MODE FIELD EFFECT

TRANSISTOR

DESCRIPTION

The UTL1426 uses UTC’s advanced trench technology to

provide excellent RDS(ON), low gate charge and operation with low

gate voltages. This device is suitable for use as a load switch or

in PWM applications.

FEATURES

* RDS(ON)< 10.5 mΩ @VGS=10V

* RDS(ON)< 12.5 mΩ @VGS=4.5V

* Low capacitance

* Low gate charge

* Fast switching capability

* Avalanche energy specified

SYMBOL

1.Gate

3.Source

2.Drain

SOP-8

Lead-free:

UTL1426L

Halogen-free: UTL1426G

ORDERING INFORMATION

Ordering Number

Normal

Lead Free Plating

Halogen Free

Package

Packing

UTL1426-S08-R

UTL1426L-S08-R

UTL1426G-S08-R

SOP-8

Tape Reel
