Data Sheet
ADM3053
Rev. A | Page 11 of 20
2.80
2.75
2.70
2.65
2.60
2.55
2.50
2.45
2.40
–40
85
60
35
10
–15
TEMPERATURE (°C)
VCC = 5V, VIO = 5V, IREF = +50µA
VCC = 5V, VIO = 5V, IREF = –50µA
VCC = 5V, VIO =5V, IREF = +5µA
VCC = 5V, VIO = 5V, IREF = –5µA
Figure 17. Reference Voltage vs. Temperature
160
140
120
100
80
60
40
20
0
–40
85
60
35
10
–15
TEMPERATURE (°C)
VCC = 5V
VIO = 5V
DATA RATE = 1Mbps
RL = 60Ω
Figure 18. Supply Current ICC vs. Temperature
140
138
136
134
132
130
128
126
124
122
120
118
4.5
5.5
5.4
5.3
5.2
5.1
5.0
4.9
4.8
4.7
4.6
SUPPLY VOLTAGE, VCC (V)
VIO = 5V
TA = 25°C
DATA RATE = 1Mbps
Figure 19. Supply Current, ICC vs. Supply Voltage VCC
–40
85
60
35
10
–15
TEMPERATURE (°C)
VCC = 5V, VIO = 5V, IOUT = –1.5mA
4.855
4.860
4.865
4.870
4.875
4.880
4.885
4.890
4.895
Figure 20. Receiver Output High Voltage vs. Temperature
–40
85
60
35
10
–15
TEMPERATURE (°C)
0
120
100
80
60
40
20
Figure 21. Receiver Output Low Voltage vs. Temperature
