ADM3053
Data Sheet
Rev. A | Page 12 of 20
TEST CIRCUITS
TxD
VOD VCANH
VCANH
VOC
RL
RL
2
2
Figure 22. Driver Voltage Measurement
CL
RxD
CANH
CANL
VID
Figure 23. Receiver Voltage Measurements
CANH
CANL
TxD
RxD
CL
RL
15pF
Figure 24. Switching Characteristics Measurements
RL
RS
10µF
100nF
10µF
100nF
10µF
100nF
10µF
100nF
ADM3053
TxD
RxD
ISOLATION
BARRIER
GND1
GND2
LOGIC SIDE
BUS SIDE
ENCODE
DECODE
DECODE
ENCODE
OSCILLATOR
RECTIFIER
REGULATOR
VISOOUT
DIGITAL ISOLATION iCoupler
isoPower DC-TO-DC CONVERTER
VIO
VISOIN
RS
CANH
CANL
VREF
REFERENCE
VOLTAGE
RECEIVER
CAN TRANSCEIVER
TxD
RS
RxD
VREF
GND2
VCC
SLOPE/
STANDBY
DRIVER
PROTECTION
VCC
Figure 25. Supply Current Measurement Test Circuit
