AD8426

Rev. 0 | Page 9 of 28

ABSOLUTE MAXIMUM RATINGS

THERMAL RESISTANCE

Table 8.

Parameter

Rating

Supply Voltage

±18 V

Output Short-Circuit Current

Indefinite

Maximum Voltage at −INx or +INx

−VS + 40 V

Minimum Voltage at −INx or +INx

+VS − 40 V

REFx Voltage

±VS

Storage Temperature Range

−65°C to +150°C

Specified Temperature Range

−40°C to +125°C

Maximum Junction Temperature

130°C

ESD

Human Body Model

1.5 kV

Charged Device Model

1.5 kV

Machine Model

100 V

The θJA value in Table 9 assumes a 4-layer JEDEC standard

board with zero airflow.

Table 9.

Package

θJA

Unit

16-Lead LFCSP (CP-16-19)

°C/W

ESD CAUTION

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
