Register description
LPS331AP
30/36
Doc ID 022112 Rev 7
AMP_CTRL
Analog front end control
Address:
2Dh
Type:
R/W
Reset:
00h
DELTA_PRESS_XL (3Ch)
Pressure offset
Address:
3Ch
Type:
R/W
Reset:
00h
DELTA_PRESS_L (3Dh)
Pressure offset
Address:
3Dh
Type:
R/W
Reset:
00h
76
54
321
0
RESERVED
SELMAIN
[7:1] RESERVED
[0] SELMAIN: Current of operational amplifier selector
‘1’ always high current
‘0’ high current during pressure acquisition and low current during temperature acquisition
76
54
321
0
DELTA7
DELTA6
DELTA5
DELTA4
DELTA3
DELTA2
DELTA1
DELTA0
[7:0] DELTA0 - DELTA7: Delta pressure register for One Point calibration
15
14
13
12
11
10
9
8
DELTA15
DELTA14
DELTA13
DELTA12
DELTA11
DELTA10
DELTA9
DELTA8
[15:8] DELTA15-DELTA8: Delta pressure register for One Point calibration
