AD6622
REV. 0
OUTLINE DIMENSIONS
Dimensions shown in inches and (mm).
128-Lead MQFP (Metric Quad Flatpack)
(S-128A)
TOP VIEW
(PINS DOWN)
1
38
39
65
64
102
128
103
0.011 (0.27)
0.007 (0.17)
0.020 (0.50)
BSC
0.555 (14.10)
0.547 (13.90)
0.685 (17.40)
0.669 (17.00)
0.791 (20.10)
0.783 (19.90)
0.921 (23.40)
0.906 (23.00)
0.041 (1.03)
0.031 (0.78)
SEATING
PLANE
0.134 (3.40)
MAX
0.003 (0.08)
MAX
0.010 (0.25)
MIN
0.110 (2.80)
0.102 (2.60)
