Electrical Characteristics (23º)
MPTS1206
Part
Number
Hold
Current
Trip
Current
Rated
Voltage
Max
Current
Typical
Power
Max Time to Trip
Resistance
Current
Time
RMIN
R1MAX
IH, A
IT, A
VMAX, Vdc
IMAX, A
Pd, W
Amp
Sec
Ω
Ω
MPTS1206L005R
0.05
0.15
60
10
0.4
0.25
1.50
3.60
50.00
MPTS1206L010R
0.10
0.25
60
10
0.4
0.50
1.00
1.60
15.00
MPTS1206L012R
0.12
0.39
48
10
0.6
1.00
0.20
1.40
6.50
MPTS1206L016R
0.16
0.45
48
10
0.6
1.00
0.30
1.10
5.00
MPTS1206L020R
0.20
0.40
30
10
0.4
8.00
0.10
0.600
2.500
MPTS1206L025R
0.25
0.50
16
40
0.6
8.00
0.08
0.550
2.300
MPTS1206L035R
0.35
0.75
16
40
0.4
8.00
0.10
0.300
1.200
MPTS1206L050R
0.50
1.00
8
40
0.4
8.00
0.10
0.150
0.700
MPTS1206L050-24R
0.50
1.00
24
100
0.6
8.00
0.10
0.150
0.750
MPTS1206L075R
0.75
1.50
6
100
0.6
8.00
0.20
0.090
0.290
MPTS1206L075-16R
0.75
1.50
16
100
0.6
8.00
0.20
0.090
0.290
MPTS1206L100R
1.00
1.80
6
100
0.6
8.00
0.30
0.055
0.210
MPTS1206L110R
1.10
2.20
6
100
0.8
8.00
0.30
0.040
0.180
MPTS1206L150R
1.50
3.00
6
100
0.8
8.00
1.00
0.030
0.120
MPTS1206L200R
2.00
3.50
6
100
0.8
8.00
1.50
0.018
0.080
IH=Hold current-maximum current at which the device will not trip at 23ºC still air.
IT=Trip current-minimum current at which the device will always trip at 23ºC still air.
V MAX=Maximum voltage device can withstand without damage at its rated current (I MAX)
I MAX= Maximum fault current device can withstand without damage at rated voltage (V MAX).
Pd=Typical power dissipated-type amount of power dissipated by the device when in the tripped state in 23ºC still air
environment.
RMIN=Minimum device resistance at 23ºC prior to tripping.
R1MAX=Maximum device resistance at 23ºC measured 1 hour after tripping or reflow soldering of 260ºC for 20 seconds.
Termination pad characteristics
Termination pad materials: Pure Tin
