Electrical Characteristics (23º)
MPTS1812
IH=Hold current-maximum current at which the device will not trip at 23ºC still air.
IT=Trip current-minimum current at which the device will always trip at 23ºC still air.
V MAX=Maximum voltage device can withstand without damage at its rated current (I MAX)
I MAX= Maximum fault current device can withstand without damage at rated voltage (V MAX).
Pd=Typical power dissipated-type amount of power dissipated by the device when in the tripped state in 23ºC still air
environment.
RMIN=Minimum device resistance at 23ºC prior to tripping.
R1MAX=Maximum device resistance at 23ºC measured 1 hour after tripping or reflow soldering of 260ºC for 20 seconds.
Termination pad characteristics
Termination pad materials: Pure Tin
Part
Number
Hold
Current
Trip
Current
Rated
Voltage
Max
Current
Typical
Power
Max Time to Trip
Resistance
Current
Time
RMIN
R1MAX
IH, A
IT, A
VMAX, Vdc
IMAX, A
Pd, W
Amp
Sec
Ω
Ω
MPTS1812L010R
0.10
0.30
60
10
0.8
8.0
0.020
1.600
15.00
MPTS1812L014R
0.14
0.30
60
10
0.8
8.0
0.008
1.200
6.500
MPTS1812L020R
0.20
0.40
30
10
0.8
8.0
0.020
0.800
5.000
MPTS1812L035R
0.35
0.70
16
40
0.8
8.0
0.100
0.320
1.500
MPTS1812L050R
0.50
1.00
16
40
0.8
8.0
0.150
0.150
1.000
MPTS1812L075R
0.75
1.50
16
40
0.8
8.0
0.200
0.110
0.450
MPTS1812L075-24R
0.75
1.50
24
40
1.0
8.0
0.200
0.110
0.290
MPTS1812L075-33R
0.75
1.50
33
40
1.0
8.0
0.200
0.110
0.400
MPTS1812L110R
1.10
2.20
8
100
0.8
8.0
0.300
0.040
0.210
MPTS1812L110-16R
1.10
2.20
16
100
0.8
8.0
0.500
0.040
0.180
MPTS1812L110-24R
1.10
2.20
24
100
1.0
8.0
0.500
0.060
0.200
MPTS1812L125R
1.25
2.50
6
40
0.8
8.0
0.400
0.050
0.140
MPTS1812L150R
1.50
3.00
8
100
0.8
8.0
0.500
0.040
0.110
MPTS1812L150-12R
1.50
3.00
12
100
1.0
8.0
0.500
0.040
0.110
MPTS1812L150-24R
1.50
3.00
24
100
1.0
8.0
1.500
0.040
0.120
MPTS1812L160R
1.60
3.20
8
100
0.8
8.0
0.500
0.030
0.100
MPTS1812L160-12R
1.60
3.20
12
100
1.0
8.0
1.000
0.030
0.100
MPTS1812L160-16R
1.60
3.20
16
100
1.0
8.0
1.000
0.030
0.100
MPTS1812L200R
2.00
3.50
8
100
1.0
8.0
2.000
0.020
0.070
MPTS1812L260R
2.60
5.00
6
100
1.0
8.0
2.500
0.015
0.047
MPTS1812L260-13R
2.60
5.00
13.2
100
1.3
8.0
5.000
0.015
0.050
MPTS1812L260-16R
2.60
5.00
16
100
1.3
8.0
5.000
0.015
0.050
MPTS1812L300R
3.00
5.00
6
100
1.0
8.0
4.000
0.012
0.040
MPTS Series
Polymeric PTC
Rev.7
